Biblioteca – Soluciones de Modelos

La biblioteca también contendrá soluciones para Visual Nand Reconstructor y PC3000 Flash. A veces, para resolver un caso es necesario utilizar las tres herramientas juntas.

Layout
  PS2251 1152_1146 v3
Mix
  Input
    Order  0/1/2/3
  Cut Bad Bytes
  Xor 5061
    Block     0x204000
    Page      0x2000
    Module    256
    BP Trash  true
  Block Pair
    Block  0x204000
    Page   0x2000
  Join by Page
    Parts  4
    Page   0x4000
  Cross Bank
    Block  0x1020000
    Bank   0x826
  Block Cut
    Block  0x1000000/0x20000
Assembler
  Block Number
    Block Size      0x1000000
    Bank Space      0x826

    Banks           00 / 0x000 / 0x737
                    01 / 0x000 / 0x66b
  Actions
    Scan
Comments
  Serg for forum 12102

  Model not finished

  Looks like even blocks unxored well
  but odd blocks is not unxored

  You can save image, use any scan software
  50% of files will be good

  Need 77 pattern
