Biblioteca – Soluciones de Modelos

La biblioteca también contendrá soluciones para Visual Nand Reconstructor y PC3000 Flash. A veces, para resolver un caso es necesario utilizar las tres herramientas juntas.

Layout
  PS2233 1074-1070 Xor C5F6_256
Mix
  Input
    Order  0/1
  Block Pair
    Block  0x200000
    Page   0x2000
  Join by Page
    Parts  2
    Page   0x4000
Assembler
  Block Number
    Block Size      0x800000
    Bank Space      0x800
    Image Cut       0x0/(0x400000)*2/(0x20000/0x10000/0x10000/0x10000/0x10000/0x
10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0
x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/
0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000
/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x1000
0/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x100
00/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10
000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x1
0000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x
10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0
x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/
0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000
/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x10000/0x1000
0/0x10000/0x20000)*15/0x0
    // Sector Updates
    Update Size     0x4000
    Update Enable   true
  Actions
    Scan
    Find Bank Size
Comments
  by Vlad forum 4775
  perfect recovery
  maybe fake flash or damaged chip
